Siemens 6ES7134-6HD01-0BA1

Product Description

Model: 6ES7134-6HD01-0BA1

Product Name: SIMATIC ET 200SP Digital Input Module

Series: ET 200SP

Module Type: Digital Input (DI), 16 channels, High Feature

Electrical Specifications: Siemens 6ES7134-6HD01-0BA1 supports 24V DC input, single-ended or differential input optional

Product Introduction

Functional Features:

16-channel digital input: can be connected to binary signal devices such as buttons, proximity switches, photoelectric sensors, etc.

High flexibility: Siemens 6ES7134-6HD01-0BA1 supports source (PNP) or sink (NPN) input configuration to adapt to different sensor types.

Diagnostic function: supports channel-level diagnosis, improving system reliability.

Modular design: adopts the compact design of ET 200SP and supports hot plugging.

Split potential design: allows different channel groups to use different reference potentials.

Technical parameters:

Input voltage: 24V DC (rated range)

Input current: typical 2mA (per channel)

Filter time: configurable (0.1ms/0.8ms/3ms, etc.), to meet different signal response requirements.

Communication interface: Siemens 6ES7134-6HD01-0BA1 communicate with PLC via PROFINET or PROFIBUS

Product details

Mechanical and electrical characteristics:

Module width: 15mm.

Wiring method: quick wiring via Base Unit (base unit), support spring clamping or screw connection.

Operating temperature: -20°C to +60°C (industrial grade environmental adaptability).

Protection level: IP20 (suitable for installation in control cabinet).

Compatibility:

Siemens 6ES7134-6HD01-0BA1 need to be used with Base Unit of ET 200SP.

Siemens 6ES7134-6HD01-0BA1 supports TIA Portal (Totally Integrated Automation) platform configuration, STEP 7 or GSD file import.

Application areas

Industrial automation:

Digital signal acquisition for production lines, packaging machinery, conveying systems and other scenarios.

Process control:

Siemens 6ES7134-6HD01-0BA1 connect limit switches, safety door locks and other equipment to achieve status monitoring.

Automotive manufacturing:

Production line control with high-density input requirements.

Energy management:

Monitoring of switch status in distribution cabinets.
